Amor Equipment

waste oil refining machine



Application:

LYE series oil filter machines can not only remove the carbon particles, deep oxides, etc., but also can filter off the harmful matters such as colloid, bitumen. After treated by the machines, the color of the treated oils looks like the new one, the quality indexes are improved also, so as to resume the performance of engine oil, keep the engine being lubricated, guarantee lubricating system of engine to work properly and prolong service life of engine oil. The series machines are special for recycling kinds of engine oil used in ships, cars and other vehicles.

Features

1.Strong capability of breaking emulsification.

2.The combination of coalescing separation and vacuum dewatering.

3.More Deeply and precisely FH rectangle filtering system. The oil will reach to the new oils nature when it was purified.

4.AMOR unique technology with H.P.M high molecule absorption material.

5.Besides the common vacuum oil purifiers function of dewatering, degassing and eliminating impurities, this machine can regenerate the seriously deteriorated oil by removing the polarity materials, such as the deep oxides, free carbon in the oil effectively

Item

 Parameter

Type
Unit

AM1.8KY

AM3KY

AM6KY

AM9KY

AM12KY

AM18KY

Technical Parameter

Flow Rate

L/H

1800

3000

6000

9000

12000

18000

Working Vacuity

Pa

80

Working Pressure

Mpa

0.35

Temperature Range



45-65

Power Supply



50Hz    380V    3-Phase 4-Wire  (or as requested)

Total Power

KW

18+2.25

30+6

2X30+6.6

3X30+8.2

4X30+10

5X30+16.5

Inlet/Outlet Diameter

mm

32 / 25

38 / 32

44 / 38

48 / 44

64 / 48

76 / 64



Size

Length

mm

1200

1500

1870

1930

2160

2250

Width

mm

950

1150

1250

1400

1600

1750

Height

mm

1600

2000

2200

2460

2650

2650

Weight

Kg

650

900

1200

1600

2200

3000

Oil Treatment Index

Breakdown Voltage

KV

70-75

Water Content

ppm

3~5

Gas Content

%

0.2

Filtering Accuracy

m

 cx1~3
